Specifications & Standards
FlameShieldTM Pure Silicone Tape meets many or all of the specifications of the following standards:
MIL-I-46852, MIL A-A-59163, TYT-200-1, P36728, TBFT201-36, NSN 5970-00-177-1627.
FlameShieldTM Pure Silicone Tape may also be certified to the following upon request (fees apply):
MIL-I-46852C Type I & II, A-A-59163 Type I & II, MIL-I-22444C, Boeing DMS2186 Type I & II, Lockheed Martin MMS J517 & 5-00857, General Electric A50A493 / A50E112 / P5384, Rohr RMS315, FAR 25.853, UL / CSA.
FlameShieldTM Pure Silicone Tape meets many or all of the specifications of the following standards:
MIL-I-46852, MIL A-A-59163, TYT-200-1, P36728, TBFT201-36, NSN 5970-00-177-1627.
FlameShieldTM Pure Silicone Tape may also be certified to the following upon request (fees apply):
MIL-I-46852C Type I & II, A-A-59163 Type I & II, MIL-I-22444C, Boeing DMS2186 Type I & II, Lockheed Martin MMS J517 & 5-00857, General Electric A50A493 / A50E112 / P5384, Rohr RMS315, FAR 25.853, UL / CSA.
Storage & Shelf Life
FlameShieldTM Pure Silicone Tape should be stored at room temperatue (70°F) and between 30 to 50% relative humidity. Storage at over 125°F can result in a reduction of bond strength and adhesion when used. Shelf life is recommended at 4 years from batch date on packaging.
FlameShieldTM Pure Silicone Tape should be stored at room temperatue (70°F) and between 30 to 50% relative humidity. Storage at over 125°F can result in a reduction of bond strength and adhesion when used. Shelf life is recommended at 4 years from batch date on packaging.
|
Example Specifications for FlameShieldTM (P/N T-SR-M025-16-TOR-20-CT) Silicone Tape (meeting Specification MIL-I-46852 Type II & A-A-59163 Type II) |
|||
| Property | Standard |
Test Result or Tolerance |
Test Method |
| Thickness | .020" (20 mil) Centre | +/- .002" | |
| Width | 1.00" | +/- .020" | |
| Length | 36 feet | +/- 6.00" | |
| Color | Oxide-Red or Black | N/A | |
| Guideline Color | Blue | N/A | |
| Operating Temperature |
-60ºC to +260ºC -76ºC to +500ºF |
||
| Shipping Weight | 140g / 5oz | ||
| Brittle Temperature | -65ºC / -85ºF | ||
| Interleave Material | .002" thick Mylar | ||
| Tensile Strength | 700 psi (minimum) | 1100 | ASTM D412 / D119 |
| Dielectric Strength | 400 V/mil (.001") | 575 |
MIL-I-46852 MIL A-A-59163 ASTM D-149 |
| Dielectric Constant | 2.94 @ 1KHz | ASTM D150 | |
| Resistance | 3 x 1014 ohms/cm3 | MIL-I-46852 | |
| Elongation | 300% (minimum) | 700 | ASTM D412 / D119 |
| Tear Strength | 85 psi (minimum) | 146 | ASTM D624 |
| Bond Strength (1" width) | 2 lbs (minimum) | 5.5 |
MIL-I-46852 ASTM D2148 |
| Adhesion |
Shall not unwind more than 1.0" after 3 minutes with 600g load |
0.12" | ASTM D2148 |
| Inclined Mandrel Tack Test (inch) | 0.25 | ASTM D2148 | |
| Water Absorption (by wt) | 3% (maximum) | 0.9% | MIL-I-46852 |
| Dissipation Factor | <0.0004 @ 1 KHz | ASTM D150 | |
|
Hardness, durometer Shore A |
55-65 | 55 |
ASTM D2148 ASTM D2240 |
www.pure-silicone-tape.com 2/12
Available in 0.5", 0.75",
1.0" and 1.5" wide tape.
Available in .020" and
.040" thickness.
Roll length
432" / 36' / 10.9m of tape.
1.0" and 1.5" wide tape.
Available in .020" and
.040" thickness.
Roll length
432" / 36' / 10.9m of tape.
